ENGINE SPECIFICATIONS
Honda, model GX340, air cooled engine
Single cylinder, 4-stroke gasoline engine
Manual recoil start.
1.6 gallon (6.1 l) integrated fuel tank
INCLUDED ACCESSORIES
Pressure gauge
Low oil alert
PUMP UNIT SPECIFICATIONS
Direct drive C.E.T. single stage centrifugal pump
Pump body made from resistant aluminum alloy
Bronze impeller
Mechanical shaft seal
Exhaust priming system, guaranteed up to 20' (6 meter) lift
One 2 1 /2" (65 mm) delivery outlet with 1 /4-turn ball valve
One 2 1 /2" (65 mm) suction inlet
Dimensions: Length: 22" (560 mm);
Width: 27 1 /4" (690 mm); Height: 20 1 /4" (515 mm)
Weight: 115 lbs (52 kg)
290 GPM @ 10 PSI
190 GPM @ 50 PSI
120 GPM @ 75 PSI
80 GPM @ 100 PSI
