ENGINE SPECIFICATIONS
Honda, model GX340, air cooled engine
Single cylinder, 4-stroke gasoline engine
12V electric start with recoil start as backup
1.6 gallon (6.1 l) integrated fuel tank
INCLUDED ACCESSORIES
Pressure gauge
Low oil alert
Quick connect for 12-V battery
PUMP UNIT SPECIFICATIONS
Direct drive C.E.T. single stage centrifugal pump
Pump body made from resistant aluminum alloy
Bronze impeller
Mechanical shaft seal
Exhaust priming system, guaranteed up to 20' (6 meter) lift
One 2 1 /2" (65 mm) NPT-M delivery outlet flange
One 2 1 /2" (65 mm) suction inlet
Dimensions: Length: 20 1/4'' (515 mm); Width: 26'' (660 mm); Height: 23 1/4'' (590 mm)
Wet weight: 132 lbs (60 kg)
290 GPM @ 10 PSI
190 GPM @ 50 PSI
120 GPM @ 75 PSI
45 GPM @ 100 PSI
