The C&S Supply 125 GPM Foam Eductor with Metering Dial and 1-1/2" Rigid Base is designed to provide efficient foam proportioning and simplified foam operations for firefighting applications. Utilizing the Venturi principle, this bypass foam eductor delivers a rated flow of 125 GPM while allowing operators to quickly select foam concentrate percentages using the integrated metering dial. The eductor can proportion Class A or Class B foam at 0.5%, 1%, 3%, or 6% with a simple turn of the dial, making it ideal for a wide range of fire suppression scenarios.
Constructed from hard-coat anodized E-Lite aluminum for corrosion resistance and long service life, the BYPP9520-DIAL includes a 48" clear pickup hose and stainless steel pickup tube. The integrated bypass switch allows operators to instantly switch between foam and water operations without removing the eductor from the hose line. Designed to reduce pump pressure requirements compared to many competitive models, this eductor provides reliable and efficient foam delivery for structural, industrial, and wildland firefighting applications.
Features
• Rated for 125 GPM foam proportioning operations
• 1-1/2" NH (NST) rigid inlet connection
• Integrated metering dial with OFF, 0.5%, 1%, 3%, and 6% settings
• Compatible with both Class A and Class B foam concentrates
• Bypass switch allows instant transition between foam and water flow
• Includes 48" clear pickup hose and stainless steel pickup tube
• Hard-coat anodized E-Lite aluminum construction
• Corrosion-resistant and lightweight design
• Designed for operation with gloved hands
• Uses approximately 15% less pump pressure than many competing eductors
• Individually tested for performance and reliability
• Repair and maintenance support available
Specifications
• Manufacturer: C&S Supply
• Model: BYPP9520-DIAL
• Product Type: Bypass Foam Eductor
• Rated Flow: 125 GPM
• Inlet Connection: 1-1/2" NST (NH)
• Foam Settings: OFF, 0.5%, 1%, 3%, 6%
• Pickup Hose Length: 48"
• Pickup Tube Material: Stainless Steel
• Construction Material: Hard-Coat Anodized E-Lite Aluminum
• Operating Principle: Venturi Foam Proportioning
• Recommended Inlet Pressure: 200 PSI
• Average Pressure Loss: Approximately 30%
• Length: 6"
• Height: 5.75"
• Weight: 3.20 lbs
• Application: Class A and Class B Foam Operations, Structural Firefighting, Industrial Fire Protection, and Wildland Firefighting
