ENGINE SPECIFICATIONS
GX390 Honda air cooled engine
Single cylinder, 4-stroke gasoline engine
12V electric start with recoil start as backup
1.6 gallon (6.1 l) integrated fuel tank
Charge coil 12V-3A
INCLUDED ACCESSORIES
Low oil alert
PUMP UNIT SPECIFICATIONS
Direct drive C.E.T. single stage centrifugal pump
Pump body made from resistant aluminum alloy
Bronze impeller
Mechanical shaft seal
Self priming system
Two 1 1/2" (38 mm) delivery outlets (NPSH threads) and one 2 1/2" (65 mm) delivery outlet (NPSH threads)
One 3" (76 mm) suction inlet (NPSH threads)
Dimensions: Length: 23" (584 mm);
Width: 27" (686 mm); Height: 20 1/2" (520 mm)
Wet weight: 143 lbs (65 kg)
MAX FLOW: 230 GPM
MAX PRESSURE: 115 PSI
190 GPM @ 25 PSI
140 GPM @ 50 PSI
60 GPM @ 100 PSI
