The 2-1/2" Mid-Range Constant Gallonage Nozzle with Pistol Grip is a fixed-flow combination nozzle designed to deliver dependable water flow and exceptional stream performance for structural, industrial, and municipal firefighting operations. Equipped with a calibrated flow disc, this nozzle provides a consistent flow rate while producing a wide, dense fog pattern that enhances firefighter protection and fire suppression effectiveness.
Constructed from lightweight, durable alloy materials, the nozzle features spinning teeth for superior fog pattern performance, an ergonomic pistol grip for improved control, and a heavy-duty chrome-plated shutoff ball for smooth operation and long service life. The nozzle can be flushed without changing the stream pattern or shutting down water flow, while the stainless steel filter mesh helps prevent debris-related blockages. Its precision-machined construction delivers reliable performance with minimal maintenance requirements.
Features
• Constant gallonage nozzle with calibrated flow disc installed
• Available flow rates of 150, 175, 200, or 250 GPM
• Wide, dense fog pattern for enhanced firefighter protection
• Spinning teeth for superior fog pattern performance
• Custom flow and pressure combinations available upon request
• Optional flow rate identification etched on the baffle
• Flow pattern detents provide positive positioning and smooth adjustment
• Laser-etched anodized label for enhanced durability and visibility
• Flushes debris without changing pattern or shutting down flow
• Ergonomic pistol grip available in multiple colors
• Heavy-duty chrome-plated shutoff ball for smooth operation and long service life
• Stainless steel filter mesh helps prevent debris blockages
• Precision-machined components require minimal maintenance
• Compatible with Foam Aeration Tube 1214
• NFPA 1964 compliant
Specifications
• Model: 1374
• Product Type: Mid-Range Constant Gallonage Combination Nozzle
• Available Flow Rates: 150, 175, 200, or 250 GPM (550, 660, 750, or 950 LPM)
• Operating Pressure: 100 PSI (7 BAR)
• Inlet Size: 2-1/2" (65 mm)
• Teeth Type: Spinning
• Material: Alloy
• Length: 11" (279 mm)
• Weight: 6.2 lbs. (2.8 kg)
• Foam Tube Compatibility: 1214
• Compliance: NFPA 1964
