The 2-1/2" Smooth Bore Quad Stacked Tip is designed to provide maximum flexibility and superior stream performance for monitor and master stream firefighting operations. Featuring four integrated smooth bore orifice sizes, this stacked tip allows operators to quickly adapt water delivery to changing fireground conditions while maintaining the exceptional reach and penetration that smooth bore streams are known for.
Constructed from lightweight hardcoat anodized aluminum, the tip offers excellent durability, corrosion resistance, and long service life. Compatible with firefighting monitors, the precision-machined smooth bore design minimizes turbulence and maximizes stream quality for efficient water application. Laser-engraved orifice markings allow for quick identification and selection of the desired discharge size in the field.
Features
• Produces concentrated water streams for maximum reach and penetration
• Compatible with firefighting monitors and master stream devices
• Quad stacked design provides four selectable smooth bore orifices
• Standard 1-3/8", 1-1/2", 1-3/4", and 2" orifice sizes
• Allows rapid adjustment of flow characteristics for changing conditions
• Lightweight hardcoat anodized aluminum construction
• Corrosion-resistant and durable design
• Precision-machined smooth bore outlets for superior stream quality
• Laser-engraved discharge size markings for easy identification
• Ideal for municipal, industrial, marine, and master stream firefighting operations
Specifications
• Model: 1120
• Product Type: Smooth Bore Quad Stacked Tip
• Inlet Size: 2-1/2" (65 mm)
• Orifice Sizes: 1-3/8", 1-1/2", 1-3/4", and 2" (35 mm, 38 mm, 44 mm, and 50 mm)
• Material: Hardcoat Anodized Alloy
• Length: 12.8" (325 mm)
• Weight: 1.7 lbs. (0.8 kg)
• Application: Monitor and Master Stream Firefighting Operations
