ENGINE SPECIFICATIONS
GXH50 Honda air cooled engine
Single cylinder, 4-stroke gasoline engine
Recoil start
0.2 gallon (0.77 l) integrated fuel tank
INCLUDED ACCESSORY
Low oil alert
* It is highly recommanded to use a foot valve at the end of the suction hose. It will be easier to prime the pump.
PUMP UNIT SPECIFICATIONS
Direct drive C.E.T. single stage centrifugal pump
Pump body made from resistant aluminum alloy
Aluminum impeller
Mechanical shaft seal
Hand priming system; guaranteed up to 6' (2 m) lift (It is highly recommanded to use a foot valve at the end of the suction hose. It will be easier to prime the pump)
One 1 1/2" (38 mm) delivery outlet with 1/4-turn ball valve
One 1 1/2" (38 mm) suction inlet
Dimensions: Length: 13" (330 mm); Width: 16 1/2" (419 mm); Height: 16" (406 mm)
Wet weight : 31 lbs (14kg)
MAX FLOW: 85 GPM
MAX PRESSURE: 60 PSI
75 GPM @ 10 PSI
55 GPM @ 25 PSI
25 GPM @ 50 PSI
