The C&S Supply 30 GPM Foam Eductor with 1" Rigid Base is a compact and efficient foam proportioning device designed for wildland, forestry, industrial, and structural firefighting applications. Utilizing the Venturi principle, this bypass eductor delivers reliable foam induction while maintaining simple operation and dependable performance in the field. The 30 GPM design is ideal for lower-flow hose lines and attack operations where accurate foam application is critical.
Constructed from durable hard-coat anodized E-Lite aluminum, the BYPP1550 features a 1" NH inlet, a 39" clear pickup hose, and a bypass valve that allows operators to switch between foam and water operations without removing the eductor from the hose line. The unit includes standard 3% and 6% metering discs, with an optional 1% metering disc available for additional flexibility. Designed to use approximately 15% less pump pressure than many competing eductors, this lightweight unit provides reliable foam delivery while helping maximize system efficiency.
Features
• Rated for 30 GPM foam proportioning operations
• 1" NH (NST) rigid inlet connection
• Includes standard 3% and 6% metering discs
• Optional 1% metering disc available
• Integrated bypass valve for switching between foam and water flow
• 39" clear pickup hose included
• Durable hard-coat anodized E-Lite aluminum construction
• Lightweight and corrosion-resistant design
• Uses approximately 15% less pump pressure than many competing eductors
• Individually tested for dependable performance
• Ideal for wildland, forestry, industrial, and structural firefighting applications
Specifications
• Manufacturer: C&S Supply
• Model: BYPP1550
• Product Type: Bypass Foam Eductor
• Rated Flow: 30 GPM
• Inlet Connection: 1" NH (NST)
• Metering Options: 3% and 6% discs included; 1% disc available
• Pickup Hose Length: 39"
• Construction Material: Hard-Coat Anodized E-Lite Aluminum
• Operating Principle: Venturi Foam Proportioning
• Recommended Inlet Pressure: 200 PSI
• Foam Pressure Loss: 39%
• Bypass Pressure Loss: 7%
• Length: 7"
• Weight: 2.80 lbs
• Dimensions: 6" W x 12" H x 4" D
• Application: Class A and Class B Foam Operations, Wildland Firefighting, Forestry Operations, Structural Firefighting, and Industrial Fire Protection
