The EVOLUTION II LED Universal Brow Mount provides powerful overhead scene lighting in a versatile mounting package designed to fit virtually any fire apparatus cab. Featuring a universal mounting bracket for simplified installation, this low-profile lighting system delivers exceptional illumination while maintaining a clean appearance and minimizing vehicle height. Ideal for fire, rescue, EMS, and specialty response vehicles, the Evolution II quickly floods the scene with bright, uniform white light upon arrival.
The Evolution II utilizes advanced LED arrays, precision optics, and a parabolic reflector system to direct 100% of the available light onto the work area. Available in V11 and V20 configurations, the lamphead produces up to 20,000 raw lumens while providing outstanding energy efficiency and a service life rated for 50,000 hours. A reinforced mounting knuckle, vibration-resistant adjustment hardware, and ergonomic molded handle ensure reliable operation in demanding emergency response environments.
Features
• Universal brow mount scene light system
• Universal mounting bracket fits most apparatus cabs
• Ideal for cab roof mounting applications
• Low-profile lamphead design
• Ultra-bright LED arrays for maximum scene illumination
• Advanced lens design focuses light where it is needed most
• Wide, uniform white light pattern
• Light color closely resembles natural sunlight
• Generates up to 20,000 raw lumens
• Produces up to 18,000 effective lumens
• Parabolic reflector and lens system maximize usable light output
• Full brightness instantly at power-up
• Instant restart capability
• Sure-grip molded handle for easy positioning
• Reinforced mounting knuckle for increased durability
• Unbalanced adjustment knob helps prevent loosening during vehicle travel
• Rated for 50,000 operating hours
• Compatible with 12V and 24V DC electrical systems
• Compact design provides more usable light from a smaller lamphead
• IP68-rated construction for protection against dust and water intrusion
Specifications
• Manufacturer: Fire Research Corporation
• Product Series: EVOLUTION II
• Product Type: LED Universal Brow Mount Scene Light
• Mounting Style: Universal Brow Mount
• Voltage: 12/24 VDC
• Lamp Life: 50,000 Hours
• Environmental Rating: IP68
Available Models
• V11
• Voltage: 12/24 VDC
• Current Draw: 7.5A / 3.75A
• Raw Lumens: 11,000
• Effective Lumens: 9,900
• V20
• Voltage: 12/24 VDC
• Current Draw: 13.0A / 6.5A
• Raw Lumens: 20,000
• Effective Lumens: 18,000
Note: The EVOLUTION II LED Universal Brow Mount combines powerful scene lighting, flexible installation, and rugged durability, making it an ideal solution for apparatus requiring high-output overhead illumination with a universal mounting configuration.
