The Kussmaul Auto Charge Pump Super Kit 53-07-1106 is a complete vehicle charging and air compressor system designed for fire apparatus, ambulances, rescue vehicles, and other emergency and specialty vehicles. By combining a battery charger, remote display, Auto Pump AC, and Super Auto Eject into one convenient package, this kit provides an integrated solution for maintaining vehicle batteries and onboard air systems while the vehicle is connected to shoreline power.
The kit includes the 091-9B-1 Auto Pump AC and a 20-amp Super Auto Eject as standard equipment. The Super Auto Eject automatically disconnects the shoreline power connection when the vehicle is started, helping prevent damage caused by driving away while the power cord is still connected. A weatherproof cover and mating connector are included with the Super Auto Eject.
Several configuration options are available to meet specific vehicle installation requirements. The standard Auto Pump AC can be upgraded to the 091-9B-1-AD Auto Pump AC with Auto Drain for an additional cost. The standard 20-amp Super Auto Eject can be substituted with a 15-amp model at no additional cost, while a 20-amp back-wire model is available for installations with limited side clearance.
Features
• Complete vehicle charging and air compressor system in one convenient kit
• Includes a battery charger, remote display, Auto Pump AC, and Super Auto Eject
• Helps maintain vehicle batteries while connected to shoreline power
• Auto Pump AC helps maintain onboard air pressure while the vehicle is parked
• Standard kit includes the 091-9B-1 Auto Pump AC
• Optional 091-9B-1-AD Auto Pump AC with Auto Drain available at an additional cost
• Standard kit includes the 091-55-20-120 20-amp Super Auto Eject
• Super Auto Eject automatically disconnects shoreline power when the vehicle is started
• Helps prevent damage caused by driving away with the shoreline power cord connected
• Super Auto Eject includes a weatherproof cover and mating connector
• Weatherproof cover available in Yellow, Blue, Red, White, Gray, or Black
• Yellow weatherproof cover supplied when no color is specified
• 091-55-15-120 15-amp Super Auto Eject may be substituted at no additional cost
• 091-55-20-120-BW 20-amp Back-Wire Super Auto Eject available at an additional cost
• Back-wire Auto Eject option is ideal for installations with limited side clearance
• Provides a convenient bundled solution for emergency and specialty vehicle electrical and air system maintenance
Specifications
• Manufacturer: Kussmaul Electronics
• Product Type: Vehicle Battery Charging and Air Compressor System Kit
• Model: Auto Charge Pump Super Kit
• Kit Part Number: 53-07-1106
• Included Components: Battery Charger, Remote Display, Auto Pump AC, and Super Auto Eject
• Standard Auto Pump: 091-9B-1 Auto Pump AC
• Optional Auto Pump: 091-9B-1-AD Auto Pump AC with Auto Drain
• Standard Auto Eject: 091-55-20-120 20 Amp Super Auto Eject
• Standard Auto Eject Wiring Configuration: Side Wire
• Optional Auto Eject: 091-55-15-120 15 Amp Super Auto Eject
• Optional Back-Wire Auto Eject: 091-55-20-120-BW 20 Amp Super Auto Eject
• Included Auto Eject Accessories: Weatherproof Cover and Mating Connector
• Weatherproof Cover Colors: Yellow, Blue, Red, White, Gray, and Black
• Default Weatherproof Cover Color: Yellow
• Application: Fire Apparatus, Ambulances, Rescue Vehicles, and Emergency or Specialty Vehicles
