Description
The Kussmaul Freedom XC Pro 3000 is a high-performance 3000-watt true sine wave inverter/charger designed to provide dependable AC power and advanced battery charging for fire apparatus, ambulances, rescue vehicles, command vehicles, and other specialty vehicle electrical systems. Combining powerful inverter performance, configurable charging capabilities, and integrated communications in a compact, lightweight package, the Freedom XC Pro 3000 is designed for demanding mobile power applications.
The Freedom XC Pro 3000 delivers 3000 watts of continuous true sine wave AC output at temperatures from -4°F to 104°F (-20°C to 40°C). An extended surge capacity provides up to 6000 watts for as long as 5 seconds, helping start motors and other electrical equipment with high initial power demands. Configurable AC output voltage and frequency settings provide additional flexibility for specialized vehicle and equipment installations.
The integrated battery charger delivers up to 100 amps of DC charging current and can charge deeply discharged batteries down to 0 volts. User-selectable charging current settings allow the system to be configured from 5 to 100 amps, while support for lithium-ion batteries and customizable battery settings provides compatibility with a wide range of battery systems.
A built-in communications card allows system monitoring and configuration through a Bluetooth-enabled app for compatible iOS and Android devices. Highly configurable settings allow OEMs and vehicle builders to tailor system operation to specific installation requirements, making the Freedom XC Pro 3000 an ideal inverter/charger solution for demanding emergency and specialty vehicle applications.
Features
• 3000-watt true sine wave inverter/charger for demanding mobile power applications
• Delivers full continuous inverter output at temperatures from -4°F to 104°F (-20°C to 40°C)
• Provides 3000 watts of continuous AC output power
• Extended surge capacity provides up to 6000 watts for as long as 5 seconds
• High surge capability helps start motors and other difficult electrical loads
• Built-in communications card provides advanced system monitoring and configuration capabilities
• Bluetooth connectivity allows monitoring and configuration through compatible iOS and Android devices
• Highly configurable settings support OEM-specific vehicle and equipment installations
• Capable of charging deeply discharged batteries down to 0 volts
• Supports lithium-ion battery charging applications
• User-selectable DC charging current from 5 to 100 amps
• Maximum DC charging current of 100 amps
• Configurable AC output voltage options for installation flexibility
• Configurable output frequency supports 60 Hz or 50 Hz operation
• High power factor at full charge rate helps provide efficient charger operation
• Compact and lightweight design simplifies installation in emergency and specialty vehicles
• Ideal for fire apparatus, ambulances, rescue vehicles, command vehicles, and specialty vehicle electrical systems
Specifications
• Manufacturer: Kussmaul Electronics
• Product Type: True Sine Wave Inverter/Charger
• Model: Freedom XC Pro 3000
• Continuous Output Power: 3000 Watts at 40°C
• Output Waveform: True Sine Wave (TSW)
• Continuous AC Output Current: 25 Amps
• Surge Power: 6000 Watts for Up to 5 Seconds
• AC Output Voltage Options: 120, 110, or 108 VAC
• Output Frequency: Configurable to 60 Hz or 50 Hz
• Peak Efficiency: 91%
• Full Load Efficiency: 84% or Greater
• AC Pass-Through Operating Voltage Range: 85 to 140 VAC
• Safe Non-Operating AC Input Voltage: Up to 240 VAC RMS
• Power Factor at Full Charge Rate: Greater Than 98%
• Minimum Battery Voltage for Charging: 0.0 VDC
• Maximum DC Output Voltage: 18.0 VDC with Custom Battery Type
• Selectable DC Output Current: 5 to 100 Amps
• Maximum DC Charge Current: 100 Amps
• Full Load Maximum AC Input Current: 25 Arms
• Operating Temperature at Full Output: -4°F to 104°F (-20°C to 40°C)
• Communications: Built-In Communications Card and Bluetooth App Connectivity
• Mobile App Compatibility: iOS and Android
