The Kussmaul Single Bar Graph Display is a vehicle-mounted dual USB charging port designed to provide convenient charging access for smartphones, tablets, and other compatible electronic devices in fire apparatus, rescue vehicles, ambulances, and other emergency or specialty vehicles. Delivering up to 3.1 amps of total charging output, the unit can charge two compatible electronic devices simultaneously.
Designed for installation in standard NGR-type vehicle switch panels, the charging port fits a 1.734" x 0.867" panel cutout for a clean, integrated installation. A built-in LED indicator provides visual confirmation that power is supplied to the charging port.
The unit can be connected to switched 12V ignition power or directly to continuous battery power, depending on the installation requirements. Integrated reverse polarity protection helps protect the charging port from incorrect electrical connections.
Features
• Dual USB charging ports for compatible electronic devices
• Provides a convenient vehicle-mounted charging location for smartphones, tablets, and other USB-powered devices
• 3.1-amp maximum total output
• Capable of charging two compatible electronic devices simultaneously
• Built-in LED indicator confirms power is supplied to the charging port
• Designed for installation in standard NGR-type vehicle switch panels
• Fits a standard 1.734" x 0.867" panel cutout
• Can be connected to switched 12V ignition power or continuous battery power
• Reverse polarity protection helps protect against incorrect electrical connections
• Simple two-wire electrical connection
• Compact panel-mounted design provides a clean, integrated vehicle installation
• Designed for fire apparatus, rescue vehicles, ambulances, and other emergency or specialty vehicle applications
• 3-year warranty
Specifications
• Manufacturer: Kussmaul Electronics
• Product Type: Dual USB Vehicle Charging Port
• Part Number: 091-219-N
• Number of USB Ports: 2
• Maximum Total Output Current: 3.1 Amps
• Input Voltage: 12 VDC
• Power Connection Options: Continuous Battery Power or Switched Ignition Power
• Recommended Fuse: 3 Amps
• Positive Connection: Red Wire
• Ground Connection: Black Wire
• Mounting Type: NGR-Type Vehicle Switch Panel
• Required Panel Cutout: 1.734" x 0.867"
• Power Indicator: Built-In LED
• Reverse Polarity Protection: Yes
• Warranty: 3 Years
