The Kussmaul Super Auto Eject Deluxe Cover with Digital Display combines an Auto Eject protective cover and vehicle battery monitoring indicator into one integrated product. Designed for compatible Kussmaul Super Auto Eject systems, the Deluxe Cover provides convenient voltage and amperage monitoring while protecting the shoreline connection on fire apparatus, rescue vehicles, ambulances, and other emergency or specialty vehicles.
The integrated digital display shows vehicle battery voltage and charging amperage using a three-digit numerical display. Multiple amperage configurations are available to support compatible Kussmaul battery chargers, including 15-, 20-, 40-, and 80-amp versions. The cover features a lid that opens 180 degrees for convenient shoreline connection access and includes a premolded rubber gasket for a secure installation.
Available in multiple color options, the Super Auto Eject Deluxe Cover with Digital Display provides an integrated solution for shoreline connection protection and vehicle charging system monitoring.
Features
• Combines a Super Auto Eject cover and digital battery monitoring indicator in one product
• Displays vehicle battery voltage and charging amperage
• Three-digit numerical display provides convenient charging system status monitoring
• Cover lid opens 180 degrees for easy shoreline connection access
• Available in multiple amperage configurations for compatible Kussmaul battery chargers
• 194 configuration rated for 40-amp charger monitoring applications
• 194A configuration rated for 15-amp charger monitoring applications
• 194B configuration rated for 20-amp charger monitoring applications
• 194C configuration rated for 80-amp charger monitoring applications
• Compatible with most Kussmaul battery chargers
• Includes premolded rubber gasket
• Available in blue, black, gray, red, white, and yellow
• Designed for fire apparatus, rescue vehicles, ambulances, and other emergency or specialty vehicle applications
• 3-year warranty
Specifications
• Manufacturer: Kussmaul Electronics
• Product Type: Super Auto Eject Deluxe Cover with Digital Battery Monitor
• Display Type: Three-Digit Digital Display
• Monitored Values: Vehicle Battery Voltage and Charging Amperage
• Available Amperage Configurations: 15, 20, 40, and 80 Amps
• Model 194: 40 Amps
• Model 194A: 15 Amps
• Model 194B: 20 Amps
• Model 194C: 80 Amps
• Voltage and Amperage Meter Accuracy: ±1%
• High Voltage Indication: Greater Than 14.8 VDC
• Low Voltage Indication: Less Than 12.3 VDC
• Maximum Input Current: 50 mA
• Cord Length: 16 Feet
• Cord Type: 20 AWG, 4-Conductor
• Operating Temperature Range: -40°F to 120°F
• Lid Opening: 180 Degrees
• Included Seal: Premolded Rubber Gasket
• Available Colors: Blue, Black, Gray, Red, White, and Yellow
• Warranty: 3 Years
