The Spectra HR LED Flat Brow Mount is a high-performance scene lighting system designed to mount directly to flat surfaces, making it ideal for installation on the roof of fire apparatus cabs and specialty response vehicles. Its low-profile design provides exceptional illumination without adding significant vehicle height, allowing crews to quickly light up emergency scenes upon arrival while maintaining a clean apparatus appearance.
Unlike traditional scene lights, the Spectra HR utilizes two distinct groups of precision-engineered lenses that simultaneously illuminate both the building face and the area directly in front of the apparatus. This unique optical design produces 28,000 lumens of bright white light without requiring lamp adjustment, helping firefighters and emergency responders improve visibility, safety, and operational efficiency at incident scenes.
Features
• Flat brow mount scene light designed for flat surface installations
• Ideal for cab roof mounting applications
• Low-profile lamphead design
• Produces 28,000 lumens of bright white light
• Dual-zone lighting system illuminates both vertical and ground-level work areas
• No lamp adjustment required for optimal scene coverage
• Upper lens group projects wide beams at multiple angles
• Lower lens group illuminates the ground area in front of the apparatus
• 72 ultra-bright white LEDs total
• 34 LEDs dedicated to upper lighting zone
• 38 LEDs dedicated to lower lighting zone
• Wide-area scene illumination improves responder visibility and safety
• Adjustable pivoting mounting arm
• Reinforced knurled locking knob for secure positioning
• Sure-Grip molded handle remains cool to the touch
• Available with or without integrated switching
• Suitable for fire apparatus, rescue vehicles, and specialty response units
Specifications
• Manufacturer: Fire Research Corporation
• Product Series: Spectra HR LED
• Product Type: Flat Brow Mount Scene Light
• Mounting Style: Flat Surface Brow Mount
• Light Output: 28,000 Lumens
• LED Configuration:
• 34 LEDs – Upper Lens Group
• 38 LEDs – Lower Lens Group
• Total LEDs: 72
• Lamphead Dimensions:
• Width: 14" (355 mm)
• Depth: 3.75" (95 mm)
• Height: 5.375" (137 mm)
• Available Voltages:
• 12/24 VDC
• 120/240 VAC
• Switch Options:
• With Switch
• Without Switch
Lighting Design
• Upper Group:
• Projects wide beams at multiple angles
• Illuminates the vertical face of buildings and elevated work areas
• Lower Group:
• Illuminates the ground area directly in front of the apparatus
• Improves visibility around personnel, equipment, and hazards
Note: The Spectra HR LED Flat Brow Mount delivers simultaneous building-face and ground-level illumination through its unique dual-lens optical system, providing broad scene coverage and enhanced firefighter safety without requiring manual lamphead adjustment.
